Serial Interface Register Maps
2.16.655 Register 1424h (offset = 1424h) [reset = 0h]
Figure 2-2918. Register 1424h
7 6 5 4 3 2 1 0
READ_INTPO_
DAC_SYNC_N
_CD_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2934. Register 1424 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_DA
C_SYNC_N_CD_0
R 0h read only register for function intpo_dac_sync_n_cd_0
2.16.656 Register 1425h (offset = 1425h) [reset = 0h]
Figure 2-2919. Register 1425h
7 6 5 4 3 2 1 0
READ_INTPO_
DAC_SYNC_N
_CD_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2935. Register 1425 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_DA
C_SYNC_N_CD_1
R 0h read only register for function intpo_dac_sync_n_cd_1
2.16.657 Register 1433h (offset = 1433h) [reset = 0h]
Figure 2-2920. Register 1433h
7 6 5 4 3 2 1 0
READ_INTPO_
GEN_INTR0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2936. Register 1433 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_GE
N_INTR0
R 0h read only register for function intpo_gen_intr0
