Texas Instruments AFE79 Series - 2.16.753 Register 1830 h (offset = 1830 h) [reset = 0 h]; 2.16.754 Register 1831 h (offset = 1831 h) [reset = 0 h]; 2.16.755 Register 1832 h (offset = 1832 h) [reset = 0 h]

www.ti.com IO Wrap Register Map
1247
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.753 Register 1830h (offset = 1830h) [reset = 0h]
Figure 2-3016. Register 1830h
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_2_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3032. Register 1830 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_2_B
1
R 0h read only register for function intpi_rxb_alc_input_2_b1
2.16.754 Register 1831h (offset = 1831h) [reset = 0h]
Figure 2-3017. Register 1831h
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_0_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3033. Register 1831 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_0_B
1
R 0h read only register for function intpi_rxc_alc_input_0_b1
2.16.755 Register 1832h (offset = 1832h) [reset = 0h]
Figure 2-3018. Register 1832h
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_1_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3034. Register 1832 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_1_B
1
R 0h read only register for function intpi_rxc_alc_input_1_b1
