Digital Top Register Map
615
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.11 Digital Top Register Map
Table 2-1186. digtop Register Map
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
100h ALARM_MASK_LSB_FOR_ALARM0[7:0]
101h ALARM_MASK_LSB_FOR_ALARM0[15:8]
102h ALARM_MASK_MSB_FOR_ALARM0[7:0]
103h ALARM_MASK_MSB_FOR_ALARM0[15:8]
104h ALARM_MASK_LSB_FOR_ALARM1[7:0]
105h ALARM_MASK_LSB_FOR_ALARM1[15:8]
106h ALARM_MASK_MSB_FOR_ALARM1[7:0]
107h ALARM_MASK_MSB_FOR_ALARM1[15:8]
10Ch SPIREAD_ALARM
110h SPI_READ_ALARM_PREMASK[7:0]
111h SPI_READ_ALARM_PREMASK[15:8]
112h SPI_READ_ALARM_PREMASK[23:16]
113h SPI_READ_ALARM_PREMASK[31:24]
114h SPI_READ_ALARM_BUS0[7:0]
115h SPI_READ_ALARM_BUS0[15:8]
116h SPI_READ_ALARM_BUS0[23:16]
117h SPI_READ_ALARM_BUS0[31:24]
118h SPI_READ_ALARM_BUS1[7:0]
119h SPI_READ_ALARM_BUS1[15:8]
11Ah SPI_READ_ALARM_BUS1[23:16]
11Bh SPI_READ_ALARM_BUS1[31:24]
150h OBS_FUNC_SPI_CHAIN_AUTOLOAD_ERROR OBS_FUNC_SPI_CHAIN_AUTOLOAD_DONE
151h
OBS_FUNC_SPI
_EFC_INFORMA
TION
OBS_FUNC_SPI
_EFC_ERROR
160h OBS_FUNC_SPI_CHAIN_AUTOLOAD_ERROR OBS_FUNC_SPI_CHAIN_AUTOLOAD_DONE
161h
OBS_FUNC_SPI
_EFC_INFORMA
TION
OBS_FUNC_SPI
_EFC_ERROR
170h
PLL_REG_SPI_
REQ_A
171h
PLL_REG_SPI_
A_ACK
190h
MISC_SPI_GLO
BAL_PDN_SIG
MISC_SPI_GLO
BAL_PDN_CTRL
2.11.1 Register 100h (offset = 100h) [reset = 0h]
Figure 2-1176. Register 100h
7 6 5 4 3 2 1 0
ALARM_MASK_LSB_FOR_ALARM0[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
