Serial Interface Register Maps
Table 2-1029. Register F9 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG0[15:8]
R 0h
Macro result register # 0. Interpretation of the contents of this
register depend on the last macro command
2.8.91 Register FAh (offset = FAh) [reset = 0h]
Figure 2-1022. Register FAh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG0[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1030. Register FA Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG0[23:16]
R 0h
Macro result register # 0. Interpretation of the contents of this
register depend on the last macro command
2.8.92 Register FBh (offset = FBh) [reset = 0h]
Figure 2-1023. Register FBh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG0[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1031. Register FB Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG0[31:24]
R 0h
Macro result register # 0. Interpretation of the contents of this
register depend on the last macro command
2.8.93 Register FCh (offset = FCh) [reset = 0h]
Figure 2-1024. Register FCh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG1[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1032. Register FC Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG1[7:0]
R 0h
Macro result register # 1. Interpretation of the contents of this
register depend on the last macro command
