www.ti.com
TX Top Register Map
689
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.12.176 Register 579h (offset = 579h) [reset = 0h]
Figure 2-1379. Register 579h
7 6 5 4 3 2 1 0
TX_PAP_HPF_
ACCU_THRES
HOLD[8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1391. Register 579 Field Descriptions
Bit Field Type Reset Description
0-0
TX_PAP_HPF_AC
CU_THRESHOLD[
8]
R/W 0h
Dual band combiner PAP high pass filter output accumulation
threshold. The threshold is on the envelope of the signal
assuming the signal takes values is in the range [-1,1). The
threshold can be programmed in the range 0 to 512. The
threshold is interpreted as programmed_value/256. For
example, value of 256 implies the envelope threshold = 1.
2.12.177 Register 57Ch (offset = 57Ch) [reset = 0h]
Figure 2-1380. Register 57Ch
7 6 5 4 3 2 1 0
TX_IP_PAP_HPF_WINDOW_COUNTER[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1392. Register 57C Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_HPF_
WINDOW_COUNT
ER[7:0]
R/W 0h
In the interface rate or Tx input (IP) PA Protection high pass
filter module, when the high pass filter output average
exceeds a thershold error hit is generated. The PA protection
can be triggered when the number of such hits in a
programmable window exceeds the count threshold. The
moving average count threshold can be programmed in the
range 0 to 2^12-1. The error accumulation counter is
programmable with value in the range 1 to 2^12-1. The error
counter threshold is programmed in the register
tx_ip_pap_hpf_error_threshold
2.12.178 Register 57Dh (offset = 57Dh) [reset = 0h]
Figure 2-1381. Register 57Dh
7 6 5 4 3 2 1 0
TX_IP_PAP_HPF_WINDOW_COUNTER[11:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
