Serial Interface Register Maps
2.12.181 Register 580h (offset = 580h) [reset = 0h]
Figure 2-1384. Register 580h
7 6 5 4 3 2 1 0
TX_PAP_DUAL_BAND_COMBINER_DET_ALAR
M_CLR
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1396. Register 580 Field Descriptions
Bit Field Type Reset Description
2-0
TX_PAP_DUAL_B
AND_COMBINER_
DET_ALARM_CLR
R/W 0h
Dual band combiner PAP detection alarm clear. Value 1 =
clear, 0 = noclear
bit [0] = Moving average mode
bit [1] = High pass filter mode
bit [2] = Reserved
2.12.182 Register 581h (offset = 581h) [reset = 0h]
Figure 2-1385. Register 581h
7 6 5 4 3 2 1 0
TX_PAP_DUAL_BAND_COMBINER_DET_ALAR
M_MASK
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1397. Register 581 Field Descriptions
Bit Field Type Reset Description
2-0
TX_PAP_DUAL_B
AND_COMBINER_
DET_ALARM_MAS
K
R/W 0h
Dual band combiner PAP detection alarm Mask. Value 1 =
mask, 0 = nomask.
bit [0] = Moving average mode
bit [1] = High Pass Filter mode
bit [2] = Reserved
2.12.183 Register 582h (offset = 582h) [reset = 0h]
Figure 2-1386. Register 582h
7 6 5 4 3 2 1 0
TX_PAP_DUAL
_BAND_COMB
INER_HPF_UP
DATE_SAMPL
ES
TX_PAP_DUAL
_BAND_COMB
INER_HPF_MO
DE_NO_AVG
TX_PAP_DUAL
_BAND_COMB
INER_MA_UPD
ATE_SAMPLE
S
TX_PAP_DUAL
_BAND_COMB
INER_MA_MO
DE_NO_AVG
R/W-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1398. Register 582 Field Descriptions
Bit Field Type Reset Description
3-3
TX_PAP_DUAL_B
AND_COMBINER_
HPF_UPDATE_SA
MPLES
R/W 0h
In dual band combiner PAP high pass filter mode, averaging
samples update pulse. A 0->1->0 transition will update the
sample config.
