Serial Interface Register Maps
2.16.595 Register 1099h (offset = 1099h) [reset = 2h]
Figure 2-2858. Register 1099h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXC_PKD
ET_3
OVR_INTPO_R
XC_PKDET_3
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2874. Register 1099 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXC_PKDET_3
R/W 1h
control to select whether the input function intpo_rxc_pkdet_3
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXC
_PKDET_3
R/W 0h
override value for intpo_rxc_pkdet_3 when
ovr_sel_intpo_rxc_pkdet_3 is made high
2.16.596 Register 109Ch (offset = 109Ch) [reset = 0h]
Figure 2-2859. Register 109Ch
7 6 5 4 3 2 1 0
POL_INTPO_R
XD_PKDET_0
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2875. Register 109C Field Descriptions
Bit Field Type Reset Description
0-0
POL_INTPO_RXD
_PKDET_0
R/W 0h
polarity control for intpo_rxd_pkdet_0. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.597 Register 109Dh (offset = 109Dh) [reset = 2h]
Figure 2-2860. Register 109Dh
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXD_PKD
ET_0
OVR_INTPO_R
XD_PKDET_0
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2876. Register 109D Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXD_PKDET_0
R/W 1h
control to select whether the input function intpo_rxd_pkdet_0
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXD
_PKDET_0
R/W 0h
override value for intpo_rxd_pkdet_0 when
ovr_sel_intpo_rxd_pkdet_0 is made high
