www.ti.com
SERDES Register Map
477
SBAU337May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-752. Register 403B Field Descriptions
Bit Field Type Reset Description
4-4 OWEN_DAC_SEL R/W 0h Overwrite enable signal for OW_DAC_SEL.
3-0 OW_DAC_SEL R/W 0h Overwrite value for DAC_SEL. Format U4.0.
2.6.33 Register 4046h (offset = 4046h) [reset = 0h]
Figure 2-747. Register 4046h
7 6 5 4 3 2 1 0
DAC_SEL CTLE_VAL
R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-753. Register 4046 Field Descriptions
Bit Field Type Reset Description
7-4 DAC_SEL R 0h Readback value of CTLE.
2-0 CTLE_VAL R 0h Readback value of CTLE.
2.6.34 Register 4047h (offset = 4047h) [reset = 0h]
Figure 2-748. Register 4047h
7 6 5 4 3 2 1 0
BP1_REACHE
D
BP2_REACHE
D
READ_STATE_NUM
R-0h R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-754. Register 4047 Field Descriptions
Bit Field Type Reset Description
7-7 BP1_REACHED R 0h
Breakpoint 1 reached indicator signal:
0h: Not reached
1h: Reached
6-6 BP2_REACHED R 0h
Breakpoint 2 reached indicator signal:
0h: Not reached
1h: Reached
4-0
READ_STATE_NU
M
R 0h Readback value of STATE number of the state machine
2.6.35 Register 4060h (offset = 4060h) [reset = 0h]
Figure 2-749. Register 4060h
7 6 5 4 3 2 1 0
EYE_MARGIN_VAL[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-755. Register 4060 Field Descriptions
Bit Field Type Reset Description
7-0
EYE_MARGIN_VA
L[7:0]
R 0h Eye Margin read back value.
