Serial Interface Register Maps
Table 2-3072. Register 1858 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_FB_
NCOSEL_1
R 0h read only register for function intpi_fb_ncosel_1
2.16.794 Register 1859h (offset = 1859h) [reset = 0h]
Figure 2-3057. Register 1859h
7 6 5 4 3 2 1 0
READ_INTPI_F
B_NCOSEL_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3073. Register 1859 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_FB_
NCOSEL_2
R 0h read only register for function intpi_fb_ncosel_2
2.16.795 Register 185Ah (offset = 185Ah) [reset = 0h]
Figure 2-3058. Register 185Ah
7 6 5 4 3 2 1 0
READ_INTPI_F
B_NCOSEL_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3074. Register 185A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_FB_
NCOSEL_3
R 0h read only register for function intpi_fb_ncosel_3
2.16.796 Register 185Bh (offset = 185Bh) [reset = 0h]
Figure 2-3059. Register 185Bh
7 6 5 4 3 2 1 0
READ_INTPI_
RX_NCOSEL_
0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3075. Register 185B Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RX_
NCOSEL_0
R 0h read only register for function intpi_rx_ncosel_0
