Serial Interface Register Maps
2.16.738 Register 1821h (offset = 1821h) [reset = 0h]
Figure 2-3001. Register 1821h
7 6 5 4 3 2 1 0
READ_INTPI_I
NTERRUPT2_
TOPMCU
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3017. Register 1821 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_INTE
RRUPT2_TOPMC
U
R 0h read only register for function intpi_interrupt2_topcm4
2.16.739 Register 1822h (offset = 1822h) [reset = 0h]
Figure 2-3002. Register 1822h
7 6 5 4 3 2 1 0
READ_INTPI_I
NTERRUPT3_
TOPMCU
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3018. Register 1822 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_INTE
RRUPT3_TOPMC
U
R 0h read only register for function intpi_interrupt3_topcm4
2.16.740 Register 1823h (offset = 1823h) [reset = 0h]
Figure 2-3003. Register 1823h
7 6 5 4 3 2 1 0
READ_INTPI_I
NTERRUPT0_
NLC
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3019. Register 1823 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_INTE
RRUPT0_NLC
R 0h read only register for function intpi_interrupt0_nlc
