Macro
Table 1-28. (continued)
Macro FB Channel frequency set
1 0x00 1 Validity FB Channel
Frequency validity
Bit 0: 1 → Channel
Frequency value is
applicable to 1FB
Bit 1: 1 → Channel
Frequency value is
applicable to 2FB.
Bits 7:2 →
RESERVED
2 0x01 1 NCO Mode 0 → Single NCO
Mode
1 → Dual NCO
Mode
2 → Tri NCO Mode
3 → Quad NCO
Mode
>3 → RESERVED
3 0x02 4 Frequency Value FB Channel
frequency for NCO
1 in specified
resolution.
In case of 1-kHz
resolution mode,
value of up to FB-
ADC-RATE is only
allowed.
4 0x06 4 Frequency Value FB Channel
frequency for NCO
2 in specified
resolution.
In case of 1-kHz
resolution mode,
value of up to FB-
ADC-RATE is only
allowed.
5 0x0A 4 Frequency Value FB Channel
frequency for NCO
3 in specified
resolution.
In case of 1-kHz
resolution mode,
value of up to FB-
ADC-RATE is only
allowed.
6 0x0E 4 Frequency Value FB Channel
frequency for NCO
4 in specified
resolution.
In case of 1-kHz
resolution mode,
value of up to FB-
ADC-RATE is only
allowed.
Memory Not used
1.2.1.14.1 Error Reporting
Table 1-29 lists the error conditions associated with this macro.
