Macro
Table 1-90. (continued)
Operand Value Comments
2 0x02 Select Dual band configuration for all 4 RX
and TX Channels
1.4.5 RX Interface Rate Configuration (Opcode – 0x29)
Table 1-91.
Operand Value Comments
1 0x0F Configure Common Setting for all RX
Channels
2 0x04 Select Interface rate of 245.76MHz
1.4.6 FB Interface Rate Configuration (Opcode – 0x2A)
Table 1-92.
Operand Value Comments
1 0x03 Configure Common Setting for all FB
Channels
2 0x06 Select Interface rate of 491.52MHz
1.4.7 TX Interface Rate Configuration (Opcode – 0x2B)
Table 1-93.
Operand Value Comments
1 0x0F Configure Common Setting for all TX
Channels
2 0x06 Select Interface rate of 491.52MHz
1.4.8 RX ADC Rate Configuration (Opcode – 0x2C)
Table 1-94.
Operand Value Comments
1 0x03 Configure Common Setting for both pairs
of RX Channels
2 0x07 Select ADC Sampling Rate of
2949.12MHz
1.4.9 FB ADC Rate Configuration (Opcode – 0x2D)
Table 1-95.
Operand Value Comments
1 0x03 Configure Common Setting for both FB
Channels
2 0x07 Select ADC Sampling Rate of
2949.12MHz
