Serial Interface Register Maps
Table 2-1071. Register 123 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG10[31:24]
R 0h
Macro result register # 10. Interpretation of the contents of this
register depend on the last macro command
2.8.133 Register 124h (offset = 124h) [reset = 0h]
Figure 2-1064. Register 124h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG11[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1072. Register 124 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG11[7:0]
R 0h
Macro result register # 11. Interpretation of the contents of this
register depend on the last macro command
2.8.134 Register 125h (offset = 125h) [reset = 0h]
Figure 2-1065. Register 125h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG11[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1073. Register 125 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG11[15:8]
R 0h
Macro result register # 11. Interpretation of the contents of this
register depend on the last macro command
2.8.135 Register 126h (offset = 126h) [reset = 0h]
Figure 2-1066. Register 126h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG11[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1074. Register 126 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG11[23:16]
R 0h
Macro result register # 11. Interpretation of the contents of this
register depend on the last macro command
