Serial Interface Register Maps
Table 2-1406. Register 591 Field Descriptions
Bit Field Type Reset Description
2-0
TX_IP_PAP_DET_
UNMASK_STATUS
R 0h
PAP dual/single band detection alarm Unmasked status.
Value 1 = trigger, 0 = notrigger.
bit [0] = Moving average mode
bit [1] = High pass filter mode
bit [2] = Reserved
2.12.192 Register 594h (offset = 594h) [reset = 0h]
Figure 2-1395. Register 594h
7 6 5 4 3 2 1 0
TX_PAP_DYN_
GPIO_ALARM
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1407. Register 594 Field Descriptions
Bit Field Type Reset Description
0-0
TX_PAP_DYN_GPI
O_ALARM
R/W 0h
PAP alarm type for output to GPIO. Dynamic or Static
versions are available.
0:static alarm output:
1:dynamic alarm output:
2.12.193 Register 596h (offset = 596h) [reset = 1h]
Figure 2-1396. Register 596h
7 6 5 4 3 2 1 0
TX_PAP_DYN_OUT_PULSE_EXTENSION[7:0]
R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1408. Register 596 Field Descriptions
Bit Field Type Reset Description
7-0
TX_PAP_DYN_OU
T_PULSE_EXTEN
SION[7:0]
R/W 1h
Pulse extension for the Dynamic version of PAP alarm going
from TxA to GPIO. Any value from 0 to 2^16-1 can be
programmed and the extension is terms of Tx digital clock
divided by 4.
2.12.194 Register 597h (offset = 597h) [reset = 2Ch]
Figure 2-1397. Register 597h
7 6 5 4 3 2 1 0
TX_PAP_DYN_OUT_PULSE_EXTENSION[15:8]
R/W-2Ch
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
