2.16.722 Register 180Dh (offset = 180Dh) [reset = 0h]
Figure 2-2985. Register 180Dh
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_2_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3001. Register 180D Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_2_B
0
R 0h read only register for function intpi_rxc_alc_input_2_b0
2.16.723 Register 180Eh (offset = 180Eh) [reset = 0h]
Figure 2-2986. Register 180Eh
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_ALC_INP
UT_0_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3002. Register 180E Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_ALC_INPUT_0_B
0
R 0h read only register for function intpi_rxd_alc_input_0_b0
2.16.724 Register 180Fh (offset = 180Fh) [reset = 0h]
Figure 2-2987. Register 180Fh
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_ALC_INP
UT_1_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3003. Register 180F Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_ALC_INPUT_1_B
0
R 0h read only register for function intpi_rxd_alc_input_1_b0
