Texas Instruments AFE79 Series User Manual

ADC JESD Register Map www.ti.com
460
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.5.215 Register 12Eh (offset = 12Eh) [reset = 0h]
Figure 2-711. Register 12Eh
7 6 5 4 3 2 1 0
0 0 0 MONITOR_SE
RDES_TXBCL
K3
MONITOR_SE
RDES_TXBCL
K2
MONITOR_SE
RDES_TXBCL
K1
MONITOR_SE
RDES_TXBCL
K0
MONITOR_JES
D_CLK_FB_P0
_MSF_RD
R/W-0h R/W-0h R/W-0h R-0h R-0h R-0h R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-716. Register 12E Field Descriptions
Bit Field Type Reset Description
7-5 0 R/W 0h Must read or write 0
4-4
MONITOR_SERDE
S_TXBCLK3
R 0h
Monitors the Serdes TXBCLOCK.
Can be cleared by setting the CLEAR_SERDES_TXBCLK3
register to 1
3-3
MONITOR_SERDE
S_TXBCLK2
R 0h
Monitors the Serdes TXBCLOCK.
Can be cleared by setting the CLEAR_SERDES_TXBCLK2
register to 1
2-2
MONITOR_SERDE
S_TXBCLK1
R 0h
Monitors the Serdes TXBCLOCK.
Can be cleared by setting the CLEAR_SERDES_TXBCLK1
register to 1
1-1
MONITOR_SERDE
S_TXBCLK0
R 0h
Monitors the Serdes TXBCLOCK.
Can be cleared by setting the CLEAR_SERDES_TXBCLK0
register to 1
0-0
MONITOR_JESD_
CLK_FB_P0_MSF_
RD
R 0h UNUSED
2.5.216 Register 130h (offset = 130h) [reset = 0h]
Figure 2-712. Register 130h
7 6 5 4 3 2 1 0
MONITOR_JES
D_SYSREF_FB
_P0
MONITOR_JES
D_SYSREF_R
X2_P2
MONITOR_JES
D_SYSREF_R
X2_P0
MONITOR_JES
D_SYSREF_R
X1_P2
MONITOR_JES
D_SYSREF_R
X1_P0
MONITOR_DD
C_RD_SYSRE
F_FB
MONITOR_DD
C_RD_SYSRE
F_RX2
MONITOR_DD
C_RD_SYSRE
F_RX1
R-0h R-0h R-0h R-0h R-0h R-0h R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-717. Register 130 Field Descriptions
Bit Field Type Reset Description
7-7
MONITOR_JESD_
SYSREF_FB_P0
R 0h
Monitors the internal sysref for FB.
Can be cleared by setting the
CLEAR_JESD_SYSREF_FB_P0 register to 1
6-6
MONITOR_JESD_
SYSREF_RX2_P2
R 0h
monitors the internal sysref for Rx.
Can be cleared by setting the
CLEAR_JESD_SYSREF_RX2_P2 register to 1
5-5
MONITOR_JESD_
SYSREF_RX2_P0
R 0h
Monitors the internal sysref for Rx.
Can be cleared by setting the
CLEAR_JESD_SYSREF_RX2_P0 register to 1
4-4
MONITOR_JESD_
SYSREF_RX1_P2
R 0h
Monitors the internal sysref for Rx.
Can be cleared by setting the
CLEAR_JESD_SYSREF_RX1_P2 register to 1
3-3
MONITOR_JESD_
SYSREF_RX1_P0
R 0h
Monitors the internal sysref for Rx.
Can be cleared by setting the
CLEAR_JESD_SYSREF_RX1_P0 register to 1
