Page #1050 background imageLoading...
Page #1050 background image
IO Wrap Register Map
www.ti.com
1050
SBAU337May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.181 Register 2F0h (offset = 2F0h) [reset = 1h]
Figure 2-2444. Register 2F0h
7 6 5 4 3 2 1 0
PULL_CTRL_GPIO_60
R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2460. Register 2F0 Field Descriptions
Bit Field Type Reset Description
2-0
PULL_CTRL_GPIO
_60
R/W 1h
Bit 0 indicates Pull up enable.
Bit <1> Indicates Pull value.
Bit <2> is unused.
2.16.182 Register 2F1h (offset = 2F1h) [reset = 2h]
Figure 2-2445. Register 2F1h
7 6 5 4 3 2 1 0
IBUF_ST_GPIO_60
R/W-2h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2461. Register 2F1 Field Descriptions
Bit Field Type Reset Description
1-0
IBUF_ST_GPIO_6
0
R/W 2h Input buffer signal strength
2.16.183 Register 2F2h (offset = 2F2h) [reset = 0h]
Figure 2-2446. Register 2F2h
7 6 5 4 3 2 1 0
ODRIV_DS_GPIO_60
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2462. Register 2F2 Field Descriptions
Bit Field Type Reset Description
1-0
ODRIV_DS_GPIO_
60
R/W 0h output buffer drive strength.
2.16.184 Register 2F4h (offset = 2F4h) [reset = 1h]
Figure 2-2447. Register 2F4h
7 6 5 4 3 2 1 0
PULL_CTRL_GPIO_61
R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
