Serial Interface Register Maps
2.16.697 Register 17F0h (offset = 17F0h) [reset = 0h]
Figure 2-2960. Register 17F0h
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_DSA_GAI
N_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2976. Register 17F0 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_DSA_GAIN_1
R 0h read only register for function intpi_rxd_dsa_gain_1
2.16.698 Register 17F1h (offset = 17F1h) [reset = 0h]
Figure 2-2961. Register 17F1h
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_DSA_GAI
N_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2977. Register 17F1 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_DSA_GAIN_2
R 0h read only register for function intpi_rxd_dsa_gain_2
2.16.699 Register 17F6h (offset = 17F6h) [reset = 0h]
Figure 2-2962. Register 17F6h
7 6 5 4 3 2 1 0
READ_INTPI_S
PIB1_CS_N
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2978. Register 17F6 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_SPIB
1_CS_N
R 0h read only register for function intpi_spib1_cs_n
