1.2 List of Macros
Table 1-2 captures the external (Host) configurations that will be used to configure and control different
features supported by AFE79XX. The internal dependencies and the definition of the operations for each
of these Macros are defined in the Macro implementation document.
Table 1-2. Macros List
Opcode Macro Name
0x11 Apply DSA Gain-Phase Compensation Macro
0x15 Mission Mode Initialization
0x20 ADC Select Configuration
0x21 System Channel Configuration
0x22 TDD/FDD Configuration
0x23 System Bands Configuration
0x29 RX Interface Rate Configuraton
0x2A FB Interface Rate Configuration
0x2B TX Interface Rate Configuration
0x2C RX ADC Rate Configuration
0x2D FB ADC Rate Configuration
0x2E TX DAC Rate Configuration
0x2F Channel Frequency(NCO) Resolution
0x30 TX Channel Frequency(NCO) Set
0x31 RX Channel Frequency(NCO) Set
0x32 FB Channel Frequency(NCO) Set
0x33 RX-FB Nyquist Band Configuration
0x34 TX Nyquist Band Configuration
0x36 Tune System
0x37 Update TX Channel Frequency Set - Single Band
0x38 Update RX Channel Frequency Set
0x39 Update FB Channel Frequency Set
0x3E Update TX Channel Frequency Set - Dual Band
0x41 RX DSA Gain Phase Factory Calibration Macro
0x42 TX DSA Gain Phase Factory Calibration Macro
0x48 TX Tone Generator Configuration
0x51 TX Attenuation Update Trigger Macro
0x55 Sleep Mode Configuration
0x57 Sleep/Active Trigger
0x58 AGC Digital Detector Configuration Macro
0x59 AGC Detector Time Constant Macro
0x5A AGC Digital Detector Relative Time Crossing Macro
0x5B AGC Digital Detector Absolute Time Crossing Macro
0x5C AGC External-AGC Configuration Macro
0x5D AGC Detectors reset by GPIO Control
0x5E AGC Internal-AGC Controller Configuration Macro
0x60 AGC Min/Max DSA Attenuation Configuration Macro
0x61 AGC External DVGA Configuration Macro
0x62 AGC Dual LNA Decay threshold Configuration
0x63 AGC Dual LNA Time Crossings
0x65 AGC Customer RF Macro
0x66 AGC External LNA Gain Control Configuration Macro
0x67 AGC Gain Step Size Configuration Macro
