Serial Interface Register Maps
2.16.631 Register 11C1h (offset = 11C1h) [reset = 2h]
Figure 2-2894. Register 11C1h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_FBCD_PK
DET_3
OVR_INTPO_F
BCD_PKDET_3
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2910. Register 11C1 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
FBCD_PKDET_3
R/W 1h
control to select whether the input function
intpo_fbcd_pkdet_3 needs to be overriden ot not. 1 indicates
override.
0-0
OVR_INTPO_FBC
D_PKDET_3
R/W 0h
override value for intpo_fbcd_pkdet_3 when
ovr_sel_intpo_fbcd_pkdet_3 is made high
2.16.632 Register 13E9h (offset = 13E9h) [reset = 0h]
Figure 2-2895. Register 13E9h
7 6 5 4 3 2 1 0
READ_INTPO_
SPIB1_SDO
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2911. Register 13E9 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_SPI
B1_SDO
R 0h read only register for function intpo_spib1_sdo
2.16.633 Register 13EAh (offset = 13EAh) [reset = 0h]
Figure 2-2896. Register 13EAh
7 6 5 4 3 2 1 0
READ_INTPO_
SPIB2_SDO
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2912. Register 13EA Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_SPI
B2_SDO
R 0h read only register for function intpo_spib2_sdo
