2.8.150 Register 135h (offset = 135h) [reset = 0h]
Figure 2-1081. Register 135h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG15[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1089. Register 135 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG15[15:8]
R 0h
Macro result register # 15. Interpretation of the contents of this
register depend on the last macro command
2.8.151 Register 136h (offset = 136h) [reset = 0h]
Figure 2-1082. Register 136h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG15[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1090. Register 136 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG15[23:16]
R 0h
Macro result register # 15. Interpretation of the contents of this
register depend on the last macro command
2.8.152 Register 137h (offset = 137h) [reset = 0h]
Figure 2-1083. Register 137h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG15[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1091. Register 137 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG15[31:24]
R 0h
Macro result register # 15. Interpretation of the contents of this
register depend on the last macro command
2.8.153 Register 138h (offset = 138h) [reset = 0h]
Figure 2-1084. Register 138h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG16[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
