Texas Instruments AFE79 Series - 2.12.202 Register 5 AAh (offset = 5 AAh) [reset = 0 h]; 2.12.203 Register 5 B0 h (offset = 5 B0 h) [reset = 0 h]; 2.12.204 Register 5 B1 h (offset = 5 B1 h) [reset = 0 h]

TX Top Register Map www.ti.com
698
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1416. Register 5A9 Field Descriptions
Bit Field Type Reset Description
7-0
TX_PAP_MEMIN_
PAP_MA_PWR_A
VG_BAND0[15:8]
R 0h
Dual band combiner PAP moving average detection output.
The linear value is interpreted as read_value/2^16.
2.12.202 Register 5AAh (offset = 5AAh) [reset = 0h]
Figure 2-1405. Register 5AAh
7 6 5 4 3 2 1 0
TX_PAP_MEMI
N_PAP_MA_P
WR_AVG_BAN
D0[16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1417. Register 5AA Field Descriptions
Bit Field Type Reset Description
0-0
TX_PAP_MEMIN_
PAP_MA_PWR_A
VG_BAND0[16]
R 0h
Dual band combiner PAP moving average detection output.
The linear value is interpreted as read_value/2^16.
2.12.203 Register 5B0h (offset = 5B0h) [reset = 0h]
Figure 2-1406. Register 5B0h
7 6 5 4 3 2 1 0
TX_IP_PAP_MA_PWR_AVG_BAND1[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1418. Register 5B0 Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_MA_P
WR_AVG_BAND1[
7:0]
R 0h
Input PAP band1 power detection module average power
output. The linear scale value is interpreted as
read_value/2^16
2.12.204 Register 5B1h (offset = 5B1h) [reset = 0h]
Figure 2-1407. Register 5B1h
7 6 5 4 3 2 1 0
TX_IP_PAP_MA_PWR_AVG_BAND1[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1419. Register 5B1 Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_MA_P
WR_AVG_BAND1[
15:8]
R 0h
Input PAP band1 power detection module average power
output. The linear scale value is interpreted as
read_value/2^16
