Serial Interface Register Maps
Table 2-211. Register 18C Field Descriptions
Bit Field Type Reset Description
7-0
DBG_FB_READ_O
UT_REG1[7:0]
R 0h
Data from first 2F mux output i.e.
mux_sel_fbab_i0_for_2r1f_ab, is sent to this status register, to
check for data toggling.
dbg_fb_read_out_reg1 and dbg_fb_read_out_reg2 has two
consecutive samples
2.3.168 Register 18Dh (offset = 18Dh) [reset = 0h]
Figure 2-209. Register 18Dh
7 6 5 4 3 2 1 0
DBG_FB_READ_OUT_REG1[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-212. Register 18D Field Descriptions
Bit Field Type Reset Description
7-0
DBG_FB_READ_O
UT_REG1[15:8]
R 0h
Data from first 2F mux output i.e.
mux_sel_fbab_i0_for_2r1f_ab, is sent to this status register, to
check for data toggling.
dbg_fb_read_out_reg1 and dbg_fb_read_out_reg2 has two
consecutive samples
2.3.169 Register 18Eh (offset = 18Eh) [reset = 0h]
Figure 2-210. Register 18Eh
7 6 5 4 3 2 1 0
DBG_FB_READ_OUT_REG2[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-213. Register 18E Field Descriptions
Bit Field Type Reset Description
7-0
DBG_FB_READ_O
UT_REG2[7:0]
R 0h
Data from first 2F mux output i.e.
mux_sel_fbab_i0_for_2r1f_ab, is sent to this status register, to
check for data toggling.
dbg_fb_read_out_reg1 and dbg_fb_read_out_reg2 has two
consecutive samples
2.3.170 Register 18Fh (offset = 18Fh) [reset = 0h]
Figure 2-211. Register 18Fh
7 6 5 4 3 2 1 0
DBG_FB_READ_OUT_REG2[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
