Serial Interface Register Maps
Table 2-1036. Register 100 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG2[7:0]
R 0h
Macro result register # 2. Interpretation of the contents of this
register depend on the last macro command
2.8.98 Register 101h (offset = 101h) [reset = 0h]
Figure 2-1029. Register 101h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG2[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1037. Register 101 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG2[15:8]
R 0h
Macro result register # 2. Interpretation of the contents of this
register depend on the last macro command
2.8.99 Register 102h (offset = 102h) [reset = 0h]
Figure 2-1030. Register 102h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG2[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1038. Register 102 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG2[23:16]
R 0h
Macro result register # 2. Interpretation of the contents of this
register depend on the last macro command
2.8.100 Register 103h (offset = 103h) [reset = 0h]
Figure 2-1031. Register 103h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG2[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1039. Register 103 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG2[31:24]
R 0h
Macro result register # 2. Interpretation of the contents of this
register depend on the last macro command
