Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1232
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.706 Register 17FDh (offset = 17FDh) [reset = 0h]
Figure 2-2969. Register 17FDh
7 6 5 4 3 2 1 0
READ_INTPI_A
DC_SYNC_N_
CD_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2985. Register 17FD Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_ADC
_SYNC_N_CD_2
R 0h read only register for function intpi_adc_sync_n_cd_2
2.16.707 Register 17FEh (offset = 17FEh) [reset = 0h]
Figure 2-2970. Register 17FEh
7 6 5 4 3 2 1 0
READ_INTPI_T
DD_EN_TXA
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2986. Register 17FE Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_TDD
_EN_TXA
R 0h read only register for function intpi_tdd_en_txa
2.16.708 Register 17FFh (offset = 17FFh) [reset = 0h]
Figure 2-2971. Register 17FFh
7 6 5 4 3 2 1 0
READ_INTPI_T
DD_EN_TXB
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2987. Register 17FF Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_TDD
_EN_TXB
R 0h read only register for function intpi_tdd_en_txb
2.16.709 Register 1800h (offset = 1800h) [reset = 0h]
Figure 2-2972. Register 1800h
7 6 5 4 3 2 1 0
READ_INTPI_T
DD_EN_TXC
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
