Serial Interface Register Maps
2.16.583 Register 1081h (offset = 1081h) [reset = 2h]
Figure 2-2846. Register 1081h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXB_PKD
ET_1
OVR_INTPO_R
XB_PKDET_1
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2862. Register 1081 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXB_PKDET_1
R/W 1h
control to select whether the input function intpo_rxb_pkdet_1
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXB
_PKDET_1
R/W 0h
override value for intpo_rxb_pkdet_1 when
ovr_sel_intpo_rxb_pkdet_1 is made high
2.16.584 Register 1084h (offset = 1084h) [reset = 0h]
Figure 2-2847. Register 1084h
7 6 5 4 3 2 1 0
POL_INTPO_R
XB_PKDET_2
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2863. Register 1084 Field Descriptions
Bit Field Type Reset Description
0-0
POL_INTPO_RXB_
PKDET_2
R/W 0h
polarity control for intpo_rxb_pkdet_2. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.585 Register 1085h (offset = 1085h) [reset = 2h]
Figure 2-2848. Register 1085h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXB_PKD
ET_2
OVR_INTPO_R
XB_PKDET_2
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2864. Register 1085 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXB_PKDET_2
R/W 1h
control to select whether the input function intpo_rxb_pkdet_2
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXB
_PKDET_2
R/W 0h
override value for intpo_rxb_pkdet_2 when
ovr_sel_intpo_rxb_pkdet_2 is made high
