Serial Interface Register Maps
2.6.182 Register 7E07h (offset = 7E07h) [reset = 0h]
Figure 2-896. Register 7E07h
7 6 5 4 3 2 1 0
FIRMWARE_DATA3[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-902. Register 7E07 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
3[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.183 Register 7E08h (offset = 7E08h) [reset = 0h]
Figure 2-897. Register 7E08h
7 6 5 4 3 2 1 0
FIRMWARE_DATA4[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-903. Register 7E08 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
4[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.184 Register 7E09h (offset = 7E09h) [reset = 0h]
Figure 2-898. Register 7E09h
7 6 5 4 3 2 1 0
FIRMWARE_DATA4[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-904. Register 7E09 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
4[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
