Serial Interface Register Maps
Table 2-1057. Register 115 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG7[15:8]
R 0h
Macro result register # 7. Interpretation of the contents of this
register depend on the last macro command
2.8.119 Register 116h (offset = 116h) [reset = 0h]
Figure 2-1050. Register 116h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG7[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1058. Register 116 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG7[23:16]
R 0h
Macro result register # 7. Interpretation of the contents of this
register depend on the last macro command
2.8.120 Register 117h (offset = 117h) [reset = 0h]
Figure 2-1051. Register 117h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG7[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1059. Register 117 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG7[31:24]
R 0h
Macro result register # 7. Interpretation of the contents of this
register depend on the last macro command
2.8.121 Register 118h (offset = 118h) [reset = 0h]
Figure 2-1052. Register 118h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG8[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1060. Register 118 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG8[7:0]
R 0h
Macro result register # 8. Interpretation of the contents of this
register depend on the last macro command
