Serial Interface Register Maps
Table 2-1043. Register 107 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG3[31:24]
R 0h
Macro result register # 3. Interpretation of the contents of this
register depend on the last macro command
2.8.105 Register 108h (offset = 108h) [reset = 0h]
Figure 2-1036. Register 108h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG4[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1044. Register 108 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG4[7:0]
R 0h
Macro result register # 4. Interpretation of the contents of this
register depend on the last macro command
2.8.106 Register 109h (offset = 109h) [reset = 0h]
Figure 2-1037. Register 109h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG4[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1045. Register 109 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG4[15:8]
R 0h
Macro result register # 4. Interpretation of the contents of this
register depend on the last macro command
2.8.107 Register 10Ah (offset = 10Ah) [reset = 0h]
Figure 2-1038. Register 10Ah
7 6 5 4 3 2 1 0
MACRO_RESULT_REG4[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1046. Register 10A Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG4[23:16]
R 0h
Macro result register # 4. Interpretation of the contents of this
register depend on the last macro command
