2.16.634 Register 1403h (offset = 1403h) [reset = 0h]
Figure 2-2897. Register 1403h
7 6 5 4 3 2 1 0
READ_INTPO_
RXA_PKDET_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2913. Register 1403 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
A_PKDET_0
R 0h read only register for function intpo_rxa_pkdet_0
2.16.635 Register 1404h (offset = 1404h) [reset = 0h]
Figure 2-2898. Register 1404h
7 6 5 4 3 2 1 0
READ_INTPO_
RXA_PKDET_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2914. Register 1404 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
A_PKDET_1
R 0h read only register for function intpo_rxa_pkdet_1
2.16.636 Register 1405h (offset = 1405h) [reset = 0h]
Figure 2-2899. Register 1405h
7 6 5 4 3 2 1 0
READ_INTPO_
RXA_PKDET_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2915. Register 1405 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
A_PKDET_2
R 0h read only register for function intpo_rxa_pkdet_2
2.16.637 Register 1406h (offset = 1406h) [reset = 0h]
Figure 2-2900. Register 1406h
7 6 5 4 3 2 1 0
READ_INTPO_
RXA_PKDET_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
