Serial Interface Register Maps
Table 2-1398. Register 582 Field Descriptions (continued)
Bit Field Type Reset Description
2-2
TX_PAP_DUAL_B
AND_COMBINER_
HPF_MODE_NO_
AVG
R/W 0h
In Dual band combiner PAP high pass filter based detection,
enable and disable control of the averaging mode.
0: Enable averaging
1: Disable averaging
1-1
TX_PAP_DUAL_B
AND_COMBINER_
MA_UPDATE_SA
MPLES
R/W 0h
In dual band combiner PAP moving average mode, averaging
samples update pulse. A 0->1->0 transition will update the
sample config.
0-0
TX_PAP_DUAL_B
AND_COMBINER_
MA_MODE_NO_A
VG
R/W 0h
Dual band combiner PAP moving average mode detection,
enable and disable control for the averaging mode.
0: Enable averaging
1: Disable moving average
2.12.184 Register 584h (offset = 584h) [reset = 0h]
Figure 2-1387. Register 584h
7 6 5 4 3 2 1 0
TX_PAP_DUAL_BAND_COMBINER_DET_ALAR
M_STATUS
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1399. Register 584 Field Descriptions
Bit Field Type Reset Description
2-0
TX_PAP_DUAL_B
AND_COMBINER_
DET_ALARM_STA
TUS
R 0h
Dual band combiner PAP detection alarm Masked status.
Value 1 = trigger, 0 = notrigger.
bit [0] = Moving average mode
bit [1] = High pass filter mode
bit [2] = Reserved
2.12.185 Register 585h (offset = 585h) [reset = 0h]
Figure 2-1388. Register 585h
7 6 5 4 3 2 1 0
TX_PAP_DUAL_BAND_COMBINER_DET_UNMA
SK_STATUS
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1400. Register 585 Field Descriptions
Bit Field Type Reset Description
2-0
TX_PAP_DUAL_B
AND_COMBINER_
DET_UNMASK_ST
ATUS
R 0h
Dual band combiner PAP detection alarm Unmasked status.
Value 1 = trigger, 0 = notrigger.
bit [0] = Moving average mode
bit [1] = High pass filter mode
bit [2] = Reserved
