Texas Instruments AFE79 Series - 2.13.421 Register 5 B9 h (offset = 5 B9 h) [reset = 0 h]; 2.13.422 Register 5 BAh (offset = 5 BAh) [reset = 0 h]; 2.13.423 Register 5 BBh (offset = 5 BBh) [reset = 0 h]

www.ti.com RX Top Register Map
835
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1845. Register 5B8 Field Descriptions
Bit Field Type Reset Description
7-0
RX_AGC_BAND1_
LNA_PHASE30[7:0
]
R/W 0h
LNA Phase for Band1 for temp index 30 in case of External
LNA Control , Phase for DVGA Index 62 in case of External
DVGA control
2.13.421 Register 5B9h (offset = 5B9h) [reset = 0h]
Figure 2-1833. Register 5B9h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE
30[9:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1846. Register 5B9 Field Descriptions
Bit Field Type Reset Description
1-0
RX_AGC_BAND1_
LNA_PHASE30[9:8
]
R/W 0h
LNA Phase for Band1 for temp index 30 in case of External
LNA Control , Phase for DVGA Index 62 in case of External
DVGA control
2.13.422 Register 5BAh (offset = 5BAh) [reset = 0h]
Figure 2-1834. Register 5BAh
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE31[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1847. Register 5BA Field Descriptions
Bit Field Type Reset Description
7-0
RX_AGC_BAND1_
LNA_PHASE31[7:0
]
R/W 0h
LNA Phase for Band1 for temp index 31 in case of External
LNA Control , Phase for DVGA Index 63 in case of External
DVGA control
2.13.423 Register 5BBh (offset = 5BBh) [reset = 0h]
Figure 2-1835. Register 5BBh
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE
31[9:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1848. Register 5BB Field Descriptions
Bit Field Type Reset Description
1-0
RX_AGC_BAND1_
LNA_PHASE31[9:8
]
R/W 0h
LNA Phase for Band1 for temp index 31 in case of External
LNA Control , Phase for DVGA Index 63 in case of External
DVGA control
