Macro
Table 1-16.
Macro RX ADC Rate configuration
Opcode 0x2C
Operand Offset Length Value Functionality Results
1 0x00 1 Validity RX ADC Rate
Validity
Bit 0: 1 → Value
specified in operand
2 is valid for RX12
Bit 1: 1 → Value
specified in operand
2 is valid for RX34
Bits 7:2 →
RESERVED
2 0x01 1 Index ADC Rate Index
Mapping from index
to actual rate is
given below.
(x = 61.44 MHz)
0 → RESERVED
1 → RESERVED
2 → 20x = 1228.8
MHz
3 → 24x = 1474.56
MHz
4 → 32x = 1966.08
MHz
5 → 36x = 2211.84
MHz
6 → 40x = 2457.6
MHz
7 → 48x = 2949.12
MHz
>7 → RESERVED
Memory Not used
1.2.1.8.1 Error Reporting
Table 1-17 lists the error conditions associated with this macro.
Table 1-17.
Error Status Registers Interpretation
Error Code 1 (16-bit)
Bit[0]: ‘1’ → Invalid RX ADC Rate Validity argument
Bit[1]: ‘1’ → Invalid ADC Rate Index argument
Error Code 2 (32-bit) Not Used
1.2.1.9 FB ADC Rate configuration
This macro specifies the Analog-to-Digital Converter (ADC) sampling rate(s) for the FB channel(s). The
supported rates are tabulated below. In case the ADC used for an FB channel is the same as that for a
particular RX channel, the ADC rate configured for both should be identical.
Table 1-18.
Macro FB ADC Rate configuration
Opcode 0x2D
Operand Offset Length Value Functionality Results
