Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1206
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.625 Register 11B5h (offset = 11B5h) [reset = 2h]
Figure 2-2888. Register 11B5h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_FBCD_PK
DET_0
OVR_INTPO_F
BCD_PKDET_0
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2904. Register 11B5 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
FBCD_PKDET_0
R/W 1h
control to select whether the input function
intpo_fbcd_pkdet_0 needs to be overriden ot not. 1 indicates
override.
0-0
OVR_INTPO_FBC
D_PKDET_0
R/W 0h
override value for intpo_fbcd_pkdet_0 when
ovr_sel_intpo_fbcd_pkdet_0 is made high
2.16.626 Register 11B8h (offset = 11B8h) [reset = 0h]
Figure 2-2889. Register 11B8h
7 6 5 4 3 2 1 0
POL_INTPO_F
BCD_PKDET_1
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2905. Register 11B8 Field Descriptions
Bit Field Type Reset Description
0-0
POL_INTPO_FBC
D_PKDET_1
R/W 0h
polarity control for intpo_fbcd_pkdet_1. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.627 Register 11B9h (offset = 11B9h) [reset = 2h]
Figure 2-2890. Register 11B9h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_FBCD_PK
DET_1
OVR_INTPO_F
BCD_PKDET_1
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2906. Register 11B9 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
FBCD_PKDET_1
R/W 1h
control to select whether the input function
intpo_fbcd_pkdet_1 needs to be overriden ot not. 1 indicates
override.
0-0
OVR_INTPO_FBC
D_PKDET_1
R/W 0h
override value for intpo_fbcd_pkdet_1 when
ovr_sel_intpo_fbcd_pkdet_1 is made high
