Serial Interface Register Maps
Table 2-1064. Register 11C Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG9[7:0]
R 0h
Macro result register # 9. Interpretation of the contents of this
register depend on the last macro command
2.8.126 Register 11Dh (offset = 11Dh) [reset = 0h]
Figure 2-1057. Register 11Dh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG9[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1065. Register 11D Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG9[15:8]
R 0h
Macro result register # 9. Interpretation of the contents of this
register depend on the last macro command
2.8.127 Register 11Eh (offset = 11Eh) [reset = 0h]
Figure 2-1058. Register 11Eh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG9[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1066. Register 11E Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG9[23:16]
R 0h
Macro result register # 9. Interpretation of the contents of this
register depend on the last macro command
2.8.128 Register 11Fh (offset = 11Fh) [reset = 0h]
Figure 2-1059. Register 11Fh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG9[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1067. Register 11F Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG9[31:24]
R 0h
Macro result register # 9. Interpretation of the contents of this
register depend on the last macro command
