www.ti.com ADC JESD Register Map
461
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-717. Register 130 Field Descriptions (continued)
Bit Field Type Reset Description
2-2
MONITOR_DDC_R
D_SYSREF_FB
R 0h
Monitors the internal sysref for DDC FB.
Can be cleared by setting the CLEAR_DDC_RD_SYSREF_FB
register to 1
1-1
MONITOR_DDC_R
D_SYSREF_RX2
R 0h
Monitors the internal sysref for DDC Rx.
Can be cleared by setting the
CLEAR_DDC_RD_SYSREF_RX2 register to 1
0-0
MONITOR_DDC_R
D_SYSREF_RX1
R 0h
Monitors the internal sysref for DDC Rx.
Can be cleared by setting the
CLEAR_DDC_RD_SYSREF_RX1 register to 1
2.5.217 Register 131h (offset = 131h) [reset = 0h]
Figure 2-713. Register 131h
7 6 5 4 3 2 1 0
MONITOR_JES
D_SYSREF_R
X2_P0_MSF_R
D
MONITOR_JES
D_SYSREF_R
X1_P0_MSF_R
D
MONITOR_JES
D_SYSREF_DI
V2_FB_P3
MONITOR_JES
D_SYSREF_DI
V2_FB_P1
MONITOR_JES
D_SYSREF_DI
V2_RX2_P2
MONITOR_JES
D_SYSREF_DI
V2_RX1_P0
MONITOR_JES
D_SYSREF_FB
_P3
MONITOR_JES
D_SYSREF_FB
_P1
R-0h R-0h R-0h R-0h R-0h R-0h R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-718. Register 131 Field Descriptions
Bit Field Type Reset Description
7-7
MONITOR_JESD_
SYSREF_RX2_P0
_MSF_RD
R 0h UNUSED
6-6
MONITOR_JESD_
SYSREF_RX1_P0
_MSF_RD
R 0h UNUSED
5-5
MONITOR_JESD_
SYSREF_DIV2_FB
_P3
R 0h
Monitors the internal sysref of FB.
Can be cleared by setting the
CLEAR_JESD_SYSREF_DIV2_FB_P3 register to 1
4-4
MONITOR_JESD_
SYSREF_DIV2_FB
_P1
R 0h
Monitors the internal sysref of FB.
Can be cleared by setting the
CLEAR_JESD_SYSREF_DIV2_FB_P1 register to 1
3-3
MONITOR_JESD_
SYSREF_DIV2_RX
2_P2
R 0h
Monitors the internal sysref of Rx.
Can be cleared by setting the
CLEAR_JESD_SYSREF_DIV2_RX2_P2 register to 1
2-2
MONITOR_JESD_
SYSREF_DIV2_RX
1_P0
R 0h
Monitors the internal sysref of Rx.
Can be cleared by setting the
CLEAR_JESD_SYSREF_DIV2_RX1_P0 register to 1
1-1
MONITOR_JESD_
SYSREF_FB_P3
R 0h
Monitors the internal sysref of FB.
Can be cleared by setting the
CLEAR_JESD_SYSREF_FB_P3 register to 1
0-0
MONITOR_JESD_
SYSREF_FB_P1
R 0h
Monitors the internal sysref of FB.
Can be cleared by setting the
CLEAR_JESD_SYSREF_FB_P1 register to 1
