www.ti.com TX Top Register Map
697
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.12.198 Register 5A4h (offset = 5A4h) [reset = 0h]
Figure 2-1401. Register 5A4h
7 6 5 4 3 2 1 0
TX_IP_PAP_MA_ACCU_TH_BAND0[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1413. Register 5A4 Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_MA_A
CCU_TH_BAND0[7
:0]
R/W 0h
Input PAP band0 moving average accumulator threshold for
the envelope of the signal (sqrt(I^2+Q^2)). The linear value is
interpreted as programmed_value/2^8
2.12.199 Register 5A5h (offset = 5A5h) [reset = 0h]
Figure 2-1402. Register 5A5h
7 6 5 4 3 2 1 0
TX_IP_PAP_M
A_ACCU_TH_
BAND0[8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1414. Register 5A5 Field Descriptions
Bit Field Type Reset Description
0-0
TX_IP_PAP_MA_A
CCU_TH_BAND0[8
]
R/W 0h
Input PAP band0 moving average accumulator threshold for
the envelope of the signal (sqrt(I^2+Q^2)). The linear value is
interpreted as programmed_value/2^8
2.12.200 Register 5A8h (offset = 5A8h) [reset = 0h]
Figure 2-1403. Register 5A8h
7 6 5 4 3 2 1 0
TX_PAP_MEMIN_PAP_MA_PWR_AVG_BAND0[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1415. Register 5A8 Field Descriptions
Bit Field Type Reset Description
7-0
TX_PAP_MEMIN_
PAP_MA_PWR_A
VG_BAND0[7:0]
R 0h
Dual band combiner PAP moving average detection output.
The linear value is interpreted as read_value/2^16.
2.12.201 Register 5A9h (offset = 5A9h) [reset = 0h]
Figure 2-1404. Register 5A9h
7 6 5 4 3 2 1 0
TX_PAP_MEMIN_PAP_MA_PWR_AVG_BAND0[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
