Macro
Table 1-34. (continued)
Macro Update TX Channel Frequency Set
2 0x01 4 Frequency Value TX Channel
frequency for NCO
1, Band 1 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
3 0x05 4 Frequency Value TX Channel
frequency for NCO
1, Band 2 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
4 0x09 4 Frequency Value TX Channel
frequency for NCO
2, Band 1 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
5 0x0D 4 Frequency Value TX Channel
frequency for NCO
2, Band 2 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
Memory Not used
1.2.1.17.1 Error Reporting
Table 1-35 lists the error conditions associated with this macro.
Table 1-35.
Error Status Registers Interpretation
Error Code 1 (16-bit) RESERVED
Error Code 2 (32-bit) RESERVED
1.2.1.18 Update TX Channel Frequency Set – Single Band
This macro can be used to update channel frequency for a specific NCO index in a single-band TX
channel without affecting the other NCO channel frequency. This macro should be called only after calling
the initial Tune System Macro.
Table 1-36.
Macro Update TX Channel Frequency Set – Single Band
Opcode 0x37
Operand Offset Length Value Functionality Results
