Texas Instruments AFE79 Series User Manual

www.ti.com IO Wrap Register Map
1213
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.648 Register 1411h (offset = 1411h) [reset = 0h]
Figure 2-2911. Register 1411h
7 6 5 4 3 2 1 0
READ_INTPO_
RXD_PKDET_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2927. Register 1411 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
D_PKDET_2
R 0h read only register for function intpo_rxd_pkdet_2
2.16.649 Register 1412h (offset = 1412h) [reset = 0h]
Figure 2-2912. Register 1412h
7 6 5 4 3 2 1 0
READ_INTPO_
RXD_PKDET_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2928. Register 1412 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
D_PKDET_3
R 0h read only register for function intpo_rxd_pkdet_3
2.16.650 Register 1417h (offset = 1417h) [reset = 0h]
Figure 2-2913. Register 1417h
7 6 5 4 3 2 1 0
READ_INTPO_
ALARM_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2929. Register 1417 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_AL
ARM_1
R 0h read only register for function intpo_alarm_1
2.16.651 Register 1418h (offset = 1418h) [reset = 0h]
Figure 2-2914. Register 1418h
7 6 5 4 3 2 1 0
READ_INTPO_
ALARM_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
