Serial Interface Register Maps
2.6.176 Register 7E01h (offset = 7E01h) [reset = 0h]
Figure 2-890. Register 7E01h
7 6 5 4 3 2 1 0
FIRMWARE_DATA0[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-896. Register 7E01 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
0[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.177 Register 7E02h (offset = 7E02h) [reset = 0h]
Figure 2-891. Register 7E02h
7 6 5 4 3 2 1 0
FIRMWARE_DATA1[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-897. Register 7E02 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
1[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.178 Register 7E03h (offset = 7E03h) [reset = 0h]
Figure 2-892. Register 7E03h
7 6 5 4 3 2 1 0
FIRMWARE_DATA1[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-898. Register 7E03 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
1[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
