Serial Interface Register Maps
2.16.719 Register 180Ah (offset = 180Ah) [reset = 0h]
Figure 2-2982. Register 180Ah
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_2_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2998. Register 180A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_2_B
0
R 0h read only register for function intpi_rxb_alc_input_2_b0
2.16.720 Register 180Bh (offset = 180Bh) [reset = 0h]
Figure 2-2983. Register 180Bh
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_0_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2999. Register 180B Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_0_B
0
R 0h read only register for function intpi_rxc_alc_input_0_b0
2.16.721 Register 180Ch (offset = 180Ch) [reset = 0h]
Figure 2-2984. Register 180Ch
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_1_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3000. Register 180C Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_1_B
0
R 0h read only register for function intpi_rxc_alc_input_1_b0
