Macro Register Map
www.ti.com
564
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1020. Register F0 Field Descriptions
Bit Field Type Reset Description
7-7
MACRO_ERROR_I
N_EXECUTION
R 0h
Value of '1' indicates that MACRO_ERROR was set due to an
error in the execution of the macro command. More
information on the nature of execution error is present in
subsequent fields.
6-6
MACRO_ERROR_I
N_OPERAND
R 0h
Value of '1' indicates that MACRO_ERROR was set due to
errors in the operands of the macro command. More
information on the nature of operand error is present in
subsequent fields.
5-5
MACRO_ERROR_
OPCODE_NOT_AL
LOWED
R 0h
Value of '1' indicates that MACRO_ERROR was set due to a
MACRO_OPCODE that is not allowed in the current state
4-4
MACRO_ERROR_I
N_OPCODE
R 0h
Value of '1' indicates that MACRO_ERROR was set due to an
invalid MACRO_OPCODE
3-3 MACRO_ERROR R 0h
Value of '1' indicates that latest macro command got
completed with some error. Information about the nature of
error is present in the subsequent register fields
2-2 MACRO_DONE R 0h Value of '1' indicates completion of the latest macro command
1-1 MACRO_ACK R 0h
Value of '1' indicates acknowledgment of the receipt of the
latest macro command
0-0 MACRO_READY R 0h
Value of '1' indicates that device is ready is receive a new
macro command. Value of '0' indicates that the latest macro
command is still under process and hence device is not ready
to receive new macro commands
2.8.82 Register F1h (offset = F1h) [reset = 0h]
Figure 2-1013. Register F1h
7 6 5 4 3 2 1 0
MACRO_ERROR_OPCODE
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1021. Register F1 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_ERROR_
OPCODE
R 0h
Field contains the 8-bit MACRO_OPCODE that resulted in the
error condition
2.8.83 Register F2h (offset = F2h) [reset = 0h]
Figure 2-1014. Register F2h
7 6 5 4 3 2 1 0
MACRO_ERROR_EXTENDED_CODE[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1022. Register F2 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_ERROR_
EXTENDED_COD
E[7:0]
R 0h
Field contains information about the nature of error (in case of
ERROR_IN_OPERAND or ERROR_IN_EXECUTION).
Interpretation of this depends on the specific
MACRO_OPCODE that caused the error.
