Serial Interface Register Maps
Table 2-2930. Register 1418 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_AL
ARM_2
R 0h read only register for function intpo_alarm_2
2.16.652 Register 1419h (offset = 1419h) [reset = 0h]
Figure 2-2915. Register 1419h
7 6 5 4 3 2 1 0
READ_INTPO_
DAC_SYNC_N
_AB_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2931. Register 1419 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_DA
C_SYNC_N_AB_0
R 0h read only register for function intpo_dac_sync_n_ab_0
2.16.653 Register 141Ah (offset = 141Ah) [reset = 0h]
Figure 2-2916. Register 141Ah
7 6 5 4 3 2 1 0
READ_INTPO_
DAC_SYNC_N
_AB_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2932. Register 141A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_DA
C_SYNC_N_AB_1
R 0h read only register for function intpo_dac_sync_n_ab_1
2.16.654 Register 141Fh (offset = 141Fh) [reset = 0h]
Figure 2-2917. Register 141Fh
7 6 5 4 3 2 1 0
READ_INTPO_
API_DONE_IN
TERRUPT
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2933. Register 141F Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_API
_DONE_INTERRU
PT
R 0h read only register for function intpo_api_done_interrupt
