Serial Interface Register Maps
Table 2-775. Register 408E Field Descriptions
Bit Field Type Reset Description
7-4
AGC_SETTING1[3:
0]
R/W 2h The AGC setting for the second highest peaking
3-0
AGC_SETTING2_
MSB
R/W 4h 4 MSBs of the AGC setting for the third highest peaking
2.6.56 Register 408Fh (offset = 408Fh) [reset = 1h]
Figure 2-770. Register 408Fh
7 6 5 4 3 2 1 0
AGC_SETTING0 AGC_SETTING1[5:4]
R/W-0h R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-776. Register 408F Field Descriptions
Bit Field Type Reset Description
7-2 AGC_SETTING0 R/W 0h The AGC setting for the highest peaking
1-0
AGC_SETTING1[5:
4]
R/W 1h The AGC setting for the second highest peaking
2.6.57 Register 4090h (offset = 4090h) [reset = 92h]
Figure 2-771. Register 4090h
7 6 5 4 3 2 1 0
AGC_SETTING4 AGC_SETTING5_MSB
R/W-24h R/W-2h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-777. Register 4090 Field Descriptions
Bit Field Type Reset Description
7-2 AGC_SETTING4 R/W 24h The AGC setting for the fifth highest peaking
1-0
AGC_SETTING5_
MSB
R/W 2h 2 MSBs of the AGC setting for the sixth highest peaking
2.6.58 Register 4091h (offset = 4091h) [reset = 9Bh]
Figure 2-772. Register 4091h
7 6 5 4 3 2 1 0
AGC_SETTING2_LSB AGC_SETTING3
R/W-2h R/W-1Bh
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-778. Register 4091 Field Descriptions
Bit Field Type Reset Description
7-6
AGC_SETTING2_L
SB
R/W 2h 2 LSBs of the AGC setting for the third highest peaking
5-0 AGC_SETTING3 R/W 1Bh The AGC setting for the fourth highest peaking
