Serial Interface Register Maps
2.8.78 Register EDh (offset = EDh) [reset = 0h]
Figure 2-1009. Register EDh
7 6 5 4 3 2 1 0
MACRO_OPERAND_REG19[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1017. Register ED Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_OPERAN
D_REG19[15:8]
R/W 0h
Macro operand register # 19. Interpretation of the operand(s)
in this register are dependent on MACRO_OPCODE
2.8.79 Register EEh (offset = EEh) [reset = 0h]
Figure 2-1010. Register EEh
7 6 5 4 3 2 1 0
MACRO_OPERAND_REG19[23:16]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1018. Register EE Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_OPERAN
D_REG19[23:16]
R/W 0h
Macro operand register # 19. Interpretation of the operand(s)
in this register are dependent on MACRO_OPCODE
2.8.80 Register EFh (offset = EFh) [reset = 0h]
Figure 2-1011. Register EFh
7 6 5 4 3 2 1 0
MACRO_OPERAND_REG19[31:24]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1019. Register EF Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_OPERAN
D_REG19[31:24]
R/W 0h
Macro operand register # 19. Interpretation of the operand(s)
in this register are dependent on MACRO_OPCODE
2.8.81 Register F0h (offset = F0h) [reset = 0h]
Figure 2-1012. Register F0h
7 6 5 4 3 2 1 0
MACRO_ERR
OR_IN_EXECU
TION
MACRO_ERR
OR_IN_OPERA
ND
MACRO_ERR
OR_OPCODE_
NOT_ALLOWE
D
MACRO_ERR
OR_IN_OPCO
DE
MACRO_ERR
OR
MACRO_DON
E
MACRO_ACK MACRO_READ
Y
R-0h R-0h R-0h R-0h R-0h R-0h R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
