Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1124
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-2662. Register 51C Field Descriptions (continued)
Bit Field Type Reset Description
1-0
BUF_DIR_CTRL_G
PIO_71
R/W 1h
Controls the direction of GPIO
0 both input and output are not selected.. can be used for
analog
1 input mode
2 output mode
3 shouldnt be used
2.16.384 Register 51Fh (offset = 51Fh) [reset = 0h]
Figure 2-2647. Register 51Fh
7 6 5 4 3 2 1 0
ACTIV_BIR_DIR_CTRL_GPIO_71 reserved
R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2663. Register 51F Field Descriptions
Bit Field Type Reset Description
3-1
ACTIV_BIR_DIR_C
TRL_GPIO_71
R/W 0h
Control to indicate whether the GPIO_71 needs dynamic
ouptu t enabling.
0 to 3 --> Static direction
4 --> Use the IO for 3 pin SPI B2 SDIO.
5 --> Use the IO for 4 pin SPI B2 SDO
6 --> Use the IO for 3 pin SPI B1 SDIO.
7 --> use the IO for 4 pin SPI B1 SDO.
0-0 reserved R/W 0h
2.16.385 Register 520h (offset = 520h) [reset = 1h]
Figure 2-2648. Register 520h
7 6 5 4 3 2 1 0
reserved reserved BUF_DIR_CTRL_GPIO_72
R/W-0h R/W-0h R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2664. Register 520 Field Descriptions
Bit Field Type Reset Description
7-5 reserved R/W 0h
4-2 reserved R/W 0h
1-0
BUF_DIR_CTRL_G
PIO_72
R/W 1h
Controls the direction of GPIO
0 both input and output are not selected.. can be used for
analog
1 input mode
2 output mode
3 shouldnt be used
