Serial Interface Register Maps
2.8.84 Register F3h (offset = F3h) [reset = 0h]
Figure 2-1015. Register F3h
7 6 5 4 3 2 1 0
MACRO_ERROR_EXTENDED_CODE[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1023. Register F3 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_ERROR_
EXTENDED_COD
E[15:8]
R 0h
Field contains information about the nature of error (in case of
ERROR_IN_OPERAND or ERROR_IN_EXECUTION).
Interpretation of this depends on the specific
MACRO_OPCODE that caused the error.
2.8.85 Register F4h (offset = F4h) [reset = 0h]
Figure 2-1016. Register F4h
7 6 5 4 3 2 1 0
MACRO_ERROR_EXTENDED_CODE_2[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1024. Register F4 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_ERROR_
EXTENDED_COD
E_2[7:0]
R 0h
Field contains information about the nature of error (in case of
ERROR_IN_OPERAND or ERROR_IN_EXECUTION).
Interpretation of this depends on the specific
MACRO_OPCODE that caused the error.
2.8.86 Register F5h (offset = F5h) [reset = 0h]
Figure 2-1017. Register F5h
7 6 5 4 3 2 1 0
MACRO_ERROR_EXTENDED_CODE_2[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1025. Register F5 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_ERROR_
EXTENDED_COD
E_2[15:8]
R 0h
Field contains information about the nature of error (in case of
ERROR_IN_OPERAND or ERROR_IN_EXECUTION).
Interpretation of this depends on the specific
MACRO_OPCODE that caused the error.
