Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1194
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.589 Register 108Dh (offset = 108Dh) [reset = 2h]
Figure 2-2852. Register 108Dh
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXC_PKD
ET_0
OVR_INTPO_R
XC_PKDET_0
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2868. Register 108D Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXC_PKDET_0
R/W 1h
control to select whether the input function intpo_rxc_pkdet_0
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXC
_PKDET_0
R/W 0h
override value for intpo_rxc_pkdet_0 when
ovr_sel_intpo_rxc_pkdet_0 is made high
2.16.590 Register 1090h (offset = 1090h) [reset = 0h]
Figure 2-2853. Register 1090h
7 6 5 4 3 2 1 0
POL_INTPO_R
XC_PKDET_1
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2869. Register 1090 Field Descriptions
Bit Field Type Reset Description
0-0
POL_INTPO_RXC
_PKDET_1
R/W 0h
polarity control for intpo_rxc_pkdet_1. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.591 Register 1091h (offset = 1091h) [reset = 2h]
Figure 2-2854. Register 1091h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXC_PKD
ET_1
OVR_INTPO_R
XC_PKDET_1
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2870. Register 1091 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXC_PKDET_1
R/W 1h
control to select whether the input function intpo_rxc_pkdet_1
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXC
_PKDET_1
R/W 0h
override value for intpo_rxc_pkdet_1 when
ovr_sel_intpo_rxc_pkdet_1 is made high
