Serial Interface Register Maps
2.16.725 Register 1810h (offset = 1810h) [reset = 0h]
Figure 2-2988. Register 1810h
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_ALC_INP
UT_2_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3004. Register 1810 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_ALC_INPUT_2_B
0
R 0h read only register for function intpi_rxd_alc_input_2_b0
2.16.726 Register 1811h (offset = 1811h) [reset = 0h]
Figure 2-2989. Register 1811h
7 6 5 4 3 2 1 0
READ_INTPI_
GLOBAL_PDN
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3005. Register 1811 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_GLO
BAL_PDN
R 0h read only register for function intpi_global_pdn
2.16.727 Register 1812h (offset = 1812h) [reset = 0h]
Figure 2-2990. Register 1812h
7 6 5 4 3 2 1 0
READ_INTPI_T
X_FB_LOOP_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3006. Register 1812 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_TX_
FB_LOOP_0
R 0h read only register for function intpi_tx_fb_loop_0
