www.ti.com DAC JESD Register Map
369
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-499. Register 150 Field Descriptions
Bit Field Type Reset Description
0-0
SERDES_FIFO_PT
R_SAMPLE
R/W 0h
When 1, internal fifo pointers are samples and save to the
registers:
serdes_fifo_wr_ptr_sample
serdes_fifo_rd_ptr_sample
2.4.267 Register 151h (offset = 151h) [reset = 0h]
Figure 2-496. Register 151h
7 6 5 4 3 2 1 0
SERDES_FIFO_RD_PTR_SAMPLE SERDES_FIFO_WR_PTR_SAMPLE
R-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-500. Register 151 Field Descriptions
Bit Field Type Reset Description
7-4
SERDES_FIFO_R
D_PTR_SAMPLE
R 0h lane0/4 fifo rd-ptr sample
3-0
SERDES_FIFO_W
R_PTR_SAMPLE
R 0h lane0/4 fifo wr-ptr sample
